KFRP FRP Rod , Aramid Fiber Reinforced Plastic Cable Strengthening 0.4mm - 5.0mm
Product Details
aramid reinforced plastic
,aramid fiber reinforced plastic
KFRP Aramid Fiber Cable Strengthen Core
FEATURES:
1) Light weight and high strength. KFRP has low density and high strength. its ratio of strength/weight and ratio of modulus/weight are higher than those of steel wire and GFRP;
2) Impact and break resistance. KFRP has much higher tensile strength(≥1700MPa),so it has much more impact and break reststance.
3) KFRP has excellent flexible and compact properties and it is easy to be bent, so that it is special used for the indoor cable layout.
Specifications: (Round KFRP:∮0.5mm/0.58mm)
| Property | Values |
| Diameter of KFRP(mm) | 0.5 |
| The Thickness of coating(EAA)(mm) | 0.04 |
| Diameter of KFRP with coating (mm) | 0.58 |
| Diameter tolerance (mm) | ±0.05 |
| Non-circularity for KFRP(%) | ≤5 |
| Tensile strength (Mpa) | ≥1700 |
| Tensile modulus(Gpa) | ≥50 |
| Elongation at break (%) | ≤3 |
| Minimum bending radius(mm) | 10*D |
| Line density (g/m) | 0.34±0.05 |
| Heat-resistant Bending Test(100℃,24h,30D) | No bur, crack and break |
| Low-temperature Bending Test(-40℃,24h,30D) | No bur, crack and break |
We also develp and produce Flat FRP strength member for different applications Tensile strength ≥1200
Fiber Reinforced Plastic FRP Rod/ Plastic Rod, which is used as the Central or peripheral strength member for fiber optical cables. Tensile strength ≥1400 on-metallic FRP Rod strength member, usually located at the center or the periphery of optical cables, serves as the important component of optical cables by supporting optic fiber bundles and enhancing cables tensile strength. Fiber Reinforced Plastic FRP Rod Product Name Fiber Reinforced Plastic FRP Rod /Plastic Rod Place
FRP/KFRP strength member for optic cable, light weight with high strength on-metallic FRP Rod strength member, usually located at the center or the periphery of optical cables, serves as the important component of optical cables by supporting optic fiber bundles and enhancing cables tensile strength. Fiber Reinforced Plastic FRP Rod Product Name Fiber Reinforced Plastic FRP Rod /Plastic Rod Place of Origin Jiangsu, China (Mainland) Diameter Range Φ 0.40 mm ~ Φ 5.00 mm Factory
Carbon fiber has the advantages of high strength, long life, corrosion resistance, light weight, low density, etc., widely used in kites, aviation model aircraft, lamp brackets, pool cue, medical equipment, sports equipment and so on. With dimensional stability, electrical and thermal conductivity, small coefficient of thermal expansion, self-lubrication and energy absorption seismic and other excellent performance.
