Home ProductsFiber Reinforced Plastic Rod

Φ1.0 Fiber Reinforced Plastic Rod Cable Reinforcement Low Density High Strength

Φ1.0 Fiber Reinforced Plastic Rod Cable Reinforcement Low Density High Strength

Φ1.0 Fiber Reinforced Plastic Rod Cable Reinforcement Low Density High Strength

Product Details:

Place of Origin: Jiangsu China
Brand Name: Dingrong
Certification: ISO-9001
Model Number: Φ0.4-Φ5.0

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Plywood reel or plastic reel
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 5000Km/month
Contact Now
Detailed Product Description
Product Name: Fiber Optic Cable Strength Member Material: FRP
Function: Strengthening Packing: Plywood Reel Or Plastic Reel
Diameter: 0.4mm-5.0mm Spool Length: 50.4km/reel, 25.2km/reel Or Customized
Appearance: No Deffets Harmful Use Such As Cracks, Uneven Spots, And Contamination

Fiber Reinforced Plastic FRP Rod/ Cable Reinforcement/KFRP strength member

Fiber Reinforced Plastic FRP Rod/ Plastic Rod, which is used as the Central or peripheral strength member for fiber optical cables.



FEATURES:

1) Light weight and high strength. KFRP has low density and high strength. its ratio of strength/weight and ratio of modulus/weight are higher than those of steel wire and GFRP;

2) Impact and break resistance. KFRP has much higher tensile strength(≥1700MPa),so it has much more impact and break reststance.

3) KFRP has excellent flexible and compact properties, so that it is special for the indoor cable layout.



Product Name Fiber Reinforced Plastic FRP Rod /Plastic Rod Place of Origin Jiangsu, China
Diameter Range Φ 0.40 mm ~ Φ 5.00 mm Factory or Not Factory
Application Central or peripheral strength member for fiber optical cables Brand Name Dingrong
Material Fiber glass and resin Technique Pultrusion
Standard ISO Certification ISO9001
Delivery Length 50.4km/reel, 25.2km/reel or customized Packing Plywood reel or plastic reel
