KFRP FRP Rod , Aramid Fiber Reinforced Plastic Cable Strengthening 0.4mm - 5.0mm

KFRP FRP Rod , Aramid Fiber Reinforced Plastic Cable Strengthening 0.4mm - 5.0mm

    • KFRP FRP Rod , Aramid Fiber Reinforced Plastic Cable Strengthening 0.4mm - 5.0mm
  • KFRP FRP Rod , Aramid Fiber Reinforced Plastic Cable Strengthening 0.4mm - 5.0mm

    Product Details:

    Place of Origin: China
    Brand Name: Dingrong
    Certification: ISO9001
    Model Number: Φ0.4-Φ5.0

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Plywood reel or plastic reel
    Delivery Time: 30days
    Payment Terms: L/C, T/T
    Supply Ability: 5000Km/month
    Contact Now
    Detailed Product Description
    Material: FRP/KFRP Product Name: FRP/KFRP Strength Member
    Function: Strengthen Diameter: 0.4mm-5.0mm
    Spool Length: 50.4km/reel, 25.2km/reel Or Customized Tensile Strength: ≥1100 Mpa
    High Light:

    aramid reinforced plastic

    ,

    aramid fiber reinforced plastic

    KFRP Aramid Fiber Cable Strengthen Core



    KFRP aramid fiber cable strebgthen core is a new type of high performance non-metallic cable strengthen core, and widely used in access network,which is used as the Central or peripheral strength member for fiber optical cables.


    FEATURES:

    1) Light weight and high strength. KFRP has low density and high strength. its ratio of strength/weight and ratio of modulus/weight are higher than those of steel wire and GFRP;

    2) Impact and break resistance. KFRP has much higher tensile strength(≥1700MPa),so it has much more impact and break reststance.

    3) KFRP has excellent flexible and compact properties and it is easy to be bent, so that it is special used for the indoor cable layout.



    Specifications: (Round KFRP:∮0.5mm/0.58mm)

    Property Values
    Diameter of KFRP(mm) 0.5
    The Thickness of coating(EAA)(mm) 0.04
    Diameter of KFRP with coating (mm) 0.58
    Diameter tolerance (mm) ±0.05
    Non-circularity for KFRP(%) ≤5
    Tensile strength (Mpa) ≥1700
    Tensile modulus(Gpa) ≥50
    Elongation at break (%) ≤3
    Minimum bending radius(mm) 10*D
    Line density (g/m) 0.34±0.05
    Heat-resistant Bending Test(100℃,24h,30D) No bur, crack and break
    Low-temperature Bending Test(-40℃,24h,30D) No bur, crack and break
