16 Cores Fiber Optic Distribution Box , Optic Fiber Distribution Box For FTTH

Fiber optic distribution box & 16 core fiber optic patch panel cross connect cabinet box

Product Description

1. This product is used in FTTH access system terminal access session, especially suitable for outdoor wall or hoop-style conditions.

2. Features and Structure Description

2.1 Case material fiberglass (SMC) material, free paint appearance, good gloss. The service life of more than 20 years

2.2 Two-tier structure design, optical splitter upper wiring layer and the lower layer of fiber splicing.

2.3 Optical splitter module drawer modular design, with strong interchangeability and versatility.

3. The main technical parameters (in line with YD, T988-2007 communication cable transfer box on request)

3.1 Working temperature: -40 ℃ + 60 ℃

3.2 Humidity: ≤95% (+ 40 ℃)

3.3 Atmospheric pressure: 70kPa ~ 106kPa

3.4 cable into the Number: 1 x 2 root (lower feed cable)

3.5 leather fibers enter the number: 8 x2 root (lower feed fiber)

3.6 Door opening angle: ≥180

3.7 Ground level discharge withstand voltage: ≥3000V (DC) / 10mA / 1min

3.8 Insulation resistance: ≥2 × 10MΩ× 500V

3.9 Dimensions: 400mm x 300mm x120mm

3.10 Weight: 5500g

4 Installation and Precautions:

4.1 Wall-mounted:

4.1.1 Installed on the wall (or under the cabinet in kind) of the size of three plastic expansion screw positions are marked;
