Protective Fiber Cable Junction Box , Fiber Optic Termination Box Anti Dust Anti Corrosion

Protective Fiber Cable Junction Box , Fiber Optic Termination Box Anti Dust Anti Corrosion

    • Protective Fiber Cable Junction Box , Fiber Optic Termination Box Anti Dust Anti Corrosion
  • Protective Fiber Cable Junction Box , Fiber Optic Termination Box Anti Dust Anti Corrosion

    Product Details:

    Place of Origin: China
    Brand Name: Dingrong
    Certification: ISO-9000
    Model Number: GFH-G288B-X1

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Paper box
    Delivery Time: 15days
    Payment Terms: L/C, T/T
    Supply Ability: 5000set/month
    Contact Now
    Detailed Product Description
    Insertion Loss: ≤0.2db UPC Return Loss: ≥50db
    APC Return Loss: ≥60db Plug durability: 1000times
    Door Opening Angle: ≥130 Insulation Resistance: ≥2 × 104MΩ / 500V
    High Light:

    outdoor cable junction box

    ,

    fiber splitter box

    GFH-G288B-X1 (Traditional Cross Connection Cabinet)



    Application:

    SMC cross connection cabinet is widely used for connecting the trunk cable and distribution cable, with the functions of terminal, storage and dispatch.



    Key Feature:

    1. SMC body ensures the property of high impact strength, good performance of waterproof, anti-dust and anti-corrosion, endure climate changes, with protection level of IP65.

    2. Complete cable routing design with fiber bend radius≥30mm.

    3. Modular tray design with the function of splicing, storage and distribution and easy installation and maintenance, can be installed up to 27 trays.

    4. 30 degree installation of adaptors, the clip-locked installation ensures the bending radius of fiber and prevents the eyes from laser’s hurt, can be installed FC, SC, ST, LC adaptors.

    5. Can be installed up to 26PCS of 1:8 PLC splitters



    Working Environment :

    1. Working temperature:-40°C~+60°C

    2. Relative humidity: ≤95% (40°C)

    3. Atmospheric pressure: 70~106KPa



    Technical Parameters

    1. Insertion loss: ≤0.2db

    2. UPC return loss: ≥50db

    3. APC return loss: ≥60db

    4. Plug durability: > 1000 times

    5. Door opening angle: ≥130

    6. Insulation resistance: ≥2 × 104MΩ / 500V

    7. Withstand voltage between grounding device and cabinet: ≥3000V (DC) / 1min





    Model No. Outside Dimensions (H*W*D) Door-opening mode Mounting Method
    GFH-G288B-X1 1450*750*360 Single-side door in the front Ground or Wall Mounting
