Aramid KFRP Material Low Expansion Impact Break Resistance Central Member Support

Aramid KFRP Material Low Expansion Impact Break Resistance Central Member Support

    • Aramid KFRP Material Low Expansion Impact Break Resistance Central Member Support
  • Aramid KFRP Material Low Expansion Impact Break Resistance Central Member Support

    Product Details:

    Place of Origin: China
    Brand Name: Dingrong
    Certification: ISO9000
    Model Number: Φ0.4-Φ0.5

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Plywood reel or plastic reel
    Delivery Time: 30days
    Payment Terms: L/C, T/T
    Supply Ability: 50000km/month
    Contact Now
    Detailed Product Description
    Product Name: Aramid KFRP Material Material: FRP
    Function: Strengthen Packing: Plywood Reel Or Plastic Reel
    Diameter: 0.4mm-5.0mm Spool Length: 50.4km/reel, 25.2km/reel Or Customized
    Tensile Strength: ≥1700 Mpa
    High Light:

    aramid frp

    ,

    aramid reinforced plastic

    KFRP/AFRP{ fiber strength material/Aramid FRP (KFRP or AFRP) central member



    KFRP STRENGTH MEMBER
    Aramid FRP (KFRP) is a new type non-metallic composite which has been designed to be used as a strenght member for access fiber optic cables.

    FEATURES AND BENEFITS:
    1) Light weight and high strength.KFRP has low density and high strength.lts ratio of strength/weight and ratio lf modulus/weight are higher than those of steel wire and GFRP;
    2) Low expansion.KFRP has a lower coefficient of thermal expansion than steel wire and GFRP in a wider temperature range;
    3) Impact and break resistance.KFRP has much higher tensile strength(≥1700MPa),so it has much more impact and break reststance.The remained tensile strength could be 1300Mpa even it is broken;
    4) Good flexibility.KFRP is flexible and easy to be bent.lts minimum bending diameter is only 24 times of the diameter of KFRP rod. ;
    5) Enable the cable to be compact,aesthetic and flexible,specially for the indoor layout.

    SIZES

    0.40 0.50 0.58



    SPECIFICATIONS

    Property Index
    Appearance No defects harmful use such as cracks,uneven spots,and contamination
    Color Natural
    Outer Diameter for coating(mm) D±0.05
    Non-circularity for coating(%) ≤5
    KFRPdeameter(mm) d±0.05
    Non-circularity for KFRP(%) ≤20
    Density(g/cm3) 1.3~1.4
    Tensile Strength(Mpa) ≥1700
    Tensile Elastic Modulus(Gpa) ≥50
    Elongation at break(%) ≤3.0
    Minimum Bending Diameter(mm) ≤12
    Heat-resistant Bending Test 80ºC,24h,Φ30mm,cracks observed
    Peel-off Strength(N) ≥20
