2.3 FRP Strength Member , Frp Materia Spool Length 50.4km Plastic Reel Packing

2.3 FRP Strength Member , Frp Materia Spool Length 50.4km Plastic Reel Packing

    • 2.3 FRP Strength Member , Frp Materia Spool Length 50.4km Plastic Reel Packing
  • 2.3 FRP Strength Member , Frp Materia Spool Length 50.4km Plastic Reel Packing

    Product Details:

    Place of Origin: china
    Brand Name: Dingrong
    Certification: ISO:9001
    Model Number: FRP:Φ2.3

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Plywood reel or plastic reel
    Delivery Time: 30days
    Payment Terms: L/C, T/T
    Supply Ability: 5000km/month
    Contact Now
    Detailed Product Description
    Product Name: FRP Strength Member Material: FRP
    Function: Strengthen Packing: Plywood Reel Or Plastic Reel
    Diameter: 2.3mm Spool Length: 50.4km/reel
    High Light:

    frp strengthening

    ,

    kfrp material



    2.3 FRP Strength Member for optic cable,Spool length 50.4km

    FRP strength member is to use epoxy resin as foundation combined with the strength of glass fiber through pultrusion technology to produce a new type of high performance non-metallic composite material which is used to make various optical fiber cables.

    Features:
    Light weight high strength, low density and high ratio of strength/weight.
    Insensitive to lightning strike, it is suitable for the area with frequent lightning and rain.
    Low expansion, it has low expansion coefficient in a wide range of temperature settings.
    Free from interference, it can resist induction interference; can be installed close to the power line and electronic devices.
    Corrosion free, which eliminates harmful gas born from metallic corrosion which can negatively, affects cable’s transmission quality.


    Specifications:
    Diameter (0.45-0.8mm)
    Length: Upon customer request

    Technical performance indicators:
    Test item
    Units(or Criteria)
    Specifications
    Appearance
    Even in color and luster, no bur and crack, smooth surface
    Diameter Tolerance
    mm
    ±0.03
    Tensile Strength
    MPa
    ≧1200
    Tensile Modulus
    GPa
    ≧50
    Elongation at break
    %
    ≦4
    Minimum bending radius
    40D
    No bur and crack or break, smooth surface, self-straighten
    High temperature bending performance
    50D,100℃±1℃, 120h
    No bur and crack or break, smooth surface, self-straighten
    Specifications in the above table conform to the industrial standard of China, the
    customized product is available on request.



    Product Usage:

    • FRP is used as strength member as it provides high tensile strength & bending properties. • The combination of Aramid yarn and a specific resin gives high tensile strength , low bending radius and light weight making it suitable for FTTH / Drop/Ariel cables.



    Product Details :

    • ARP provides strength to the cable with low bending radius . • ARP prevents cable buckling with high modulus. • ARP is very light weight. • Various length options provide flexibility & throughput on production floor.
