Product Details:
Payment & Shipping Terms:
|
| Technique: | FRP Extruded | Processing Service: | Bending, Moulding, Cutting |
|---|---|---|---|
| Function: | Strengthen | Packing: | Plywood Reel Or Plastic Reel |
| Diameter: | 0.4mm-5.0mm | Spool Length: | 50.4km/reel, 25.2km/reel Or Customized |
| Appearance: | No Deffets Harmful Use Such As Cracks, Uneven Spots, And Contamination | ||
| Highlight: | Cable Core Fiberglass Frp Rod,FRP Extruded glass Rod,Reinforced glass Frp Rod |
||
FRP Optical Cable Core Fiberglass Rod Glass Fiber Reinforced GFRP
The structural strength of optical cable is an important index of the mechanical properties of optical cable. As one of the structural components of fixed optical cable, the FRP reinforcing core plays an important role in strengthening the tensile and compressive capacity of optical cable.
FRP glass fiber reinforced core, as a kind of structural strengthening element of non-metallic fiber optic cable, is widely accepted and used by the fiber optic cable industry. It is a non-metallic bearing core with good price and performance generally recognized by the fiber optic cable industry at home and abroad. To produce qualified FRP, the key lies in the reasonable selection of reinforcement materials (glass fiber), base materials (resin) and curing process.
KFRP Specifications:
| Property | Values |
| Diameter of KFRP(mm) | 0.5 |
| The Thickness of coating(EAA)(mm) | 0.04 |
| Diameter of KFRP with coating (mm) | 0.58 |
| Diameter tolerance (mm) | ±0.05 |
| Non-circularity for KFRP(%) | ≤5 |
| Tensile strength (Mpa) | ≥1700 |
| Tensile modulus(Gpa) | ≥50 |
| Elongation at break (%) | ≤3 |
| Minimum bending radius(mm) | 10*D |
| Line density (g/m) | 0.34±0.05 |
| Heat-resistant Bending Test(100℃,24h,30D) | No bur, crack and break |
| Low-temperature Bending Test(-40℃,24h,30D) | No bur, crack and break |
Technical characteristics:
1. It has the characteristics of lightweight and high strength.
2. It has good corrosion resistance and impact resistance. This optical cable is rust-proof, tooth-biting proof, and ant-proof.
3. The surface is smooth and the size is more stable.
4. The chemical reaction between metal and other optical cable materials will not affect the optical fiber transmission index.
5. It is not sensitive to electric shock current, and is suitable for multi lightning, multi rain, and another climate environment
areas; the fiber optic cable with FRP reinforcement core can be installed close to the power line and power supply device, and will not be interfered by the induced current generated by the power line or power supply device.
