0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density

0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density

  • 0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density
0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density
Product Details:
Place of Origin: Jiangsu China
Brand Name: Dingrong
Certification: ISO-9001
Model Number: Φ0.4-Φ5.0
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Plywood reel or plastic reel
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 5000Km/month
Contact Now
Detailed Product Description
Product Name: FRP Strength Member For Fiber Cable Material: FRP Fiber Reinforced Plastic
Function: Strengthen Packing: Plywood Reel Or Plastic Reel
Diameter: 0.4mm-5.0mm Spool Length: 50.4km/reel, 25.2km/reel Or Customized
Appearance: No Deffets Harmful Use Such As Cracks, Uneven Spots, And Contamination
High Light:

frp rod

,

frp fiber reinforced plastic

Fiber Reinforced Plastic KFRP Rod/Cable Reinforcement/KFRP(FRP) strength member

KFRP Specifications:

Property Values
Diameter of KFRP(mm) 0.5
The Thickness of coating(EAA)(mm) 0.04
Diameter of KFRP with coating (mm) 0.58
Diameter tolerance (mm) ±0.05
Non-circularity for KFRP(%) ≤5
Tensile strength (Mpa) ≥1700
Tensile modulus(Gpa) ≥50
Elongation at break (%) ≤3
Minimum bending radius(mm) 10*D
Line density (g/m) 0.34±0.05
Heat-resistant Bending Test(100℃,24h,30D) No bur, crack and break
Low-temperature Bending Test(-40℃,24h,30D) No bur, crack and break
