Impact Resistance KFRP Material , Strength Member For Optical Fiber Cables
Product Details
aramid reinforced plastic
,kevlar fiber epoxy reinforced plastic
KFRP/Aramid Rod Strength Member for Optical Fiber Cables
ARP Features :
1. Light weight and high strength, both the strength and modulus of ARP are better than that of steel and fiberglass strength member.
2. Low expansion, ARP covers a wide range of temperatures; the linear expansion coefficient is less than that of steel and fiberglass strength member;
3. Impact resistance, resistance to fracture, Hongbo ARP reaches not only ultra-high tensile strength (≥1600Mpa), even in case of breakage it can still maintain a tensile strength of about 1300Mpa ;
4. Good flexibility, the light and soft texture allows it to bend easily; the minimum bending diameter is only 24 times of the diameter of the rod;
5. Indoor fiber optic cable with compact structure, excellent bending properties, especially suitable for complex wiring indoor environment.
Aramid FRP (KFRP or AFRP) central member/KFRP strength material Product Description Aramid FRP (KFRP or AFRP) central member is a new kind of non-metallic strength member for fiber optic cables. Specification Of KFRP Property Index Appearance No deffets harmful use such as cracks, uneven spots, and contamination Non-circularity for KFRP ≤5% Tensile strength ≥1700 Mpa Tensile modulus ≥50 Gpa Elongation at break ≤3 % Minimum bending radius 10*D mm Line density (g/m) 0.34±0.05
KFRP (KFRP or AFRP) central member/KFRP strength material/Aramid FRP strenght member. Product Description Aramid FRP (KFRP or AFRP) central member is a new kind of non-metallic strength member for fiber optic cables. Specification Of KFRP Property Index Appearance No deffets harmful use such as cracks, uneven spots, and contamination Non-circularity for KFRP ≤5% Tensile strength ≥1700 Mpa Tensile modulus ≥50 Gpa Elongation at break ≤3 % Minimum bending radius 10*D mm Line
Aramid FRP (KFRP or AFRP) central member/KFRP strength material Product Description Aramid FRP (KFRP or AFRP) central member is a new kind of non-metallic strength member for fiber optic cables. Specification Of KFRP Property Index Appearance No deffets harmful use such as cracks, uneven spots, and contamination Non-circularity for KFRP ≤5% Tensile strength ≥1700 Mpa Tensile modulus ≥50 Gpa Elongation at break ≤3 % Minimum bending radius 10*D mm Line density (g/m) 0.34±0.05
Our mission is to offer "High Quality" & "Good Service" & "Fast Delivery" to help our clients to gain more profits.
