Wuxi Dingrong Composite Material Technology Co. Ltd
We grow with you！
 |
| Place of Origin: | China |
| Brand Name: | Dingrong |
| Certification: | ISO9001 |
| Model Number: | Φ0.4-Φ5.0 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood reel or plastic reel |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000Km/month |
| Minimum Bending Radius(mm): | 40*D | Density (g/cm3): | 2.05-2.15 |
|---|---|---|---|
| Function: | Strengthen | Diameter: | 0.4mm-5.0mm |
| Spool Length: | 50.4km/reel, 25.2km/reel Or Customized | Tensile Modulus: | ≥50 Gpa |
| Highlight: | frp member,frp strength member |
||
FRP Glass fiber cable strengthen core
1, Nonmetallic material,not sensitive to shock,applying to lightning, rainy climate environment area
2,The optical cable with the FRP strengthen core can be installed next to power cord and power equipment, not being interfered by the inductive current generated by the power cord or the power equipment.
3, Compared with metal core, FRP won't produce the gas generated by chemical reactions between metal and factice,so it won't influence the optical fiber transmission index.
4, Compared with metal core, FRP has high tensile strength and light weight.
5, FRP fiber optic cable core can prevent bullet,teeth and ants.
Specification: diameter(unit:mm)
|
0.40
|
0.45
|
0.50
|
0.60
|
0.80
|
1.00
|
1.20
|
1.25
|
1.30
|
1.40
|
|
1.50
|
1.60
|
1.80
|
2.00
|
2.10
|
2.20
|
2.30
|
2.40
|
2.50
|
2.60
|
|
2.70
|
2.80
|
3.00
|
3.20
|
3.30
|
3.50
|
3.70
|
4.00
|
4.50
|
5.00
|
Product length
|
Inspecting items
|
Technical Parameter
|
|
Appearance
|
No crack and impurity on surface
|
|
Color
|
Nature color
|
|
Outer diameter (mm)
|
D±0.05
|
|
Flatness ratio(%)
|
≤5
|
|
KFRP outer diameter (mm)
|
d±0.05
|
|
Flatness ratio of KFRP(%)
|
≤20
|
|
Density (g/cm3)
|
1.3～1.4
|
|
Tensile Strength (Mpa)
|
≥1700
|
|
Tensile modules of elasticity(Gpa)
|
≥50
|
|
Breaking elongation(%)
|
≤3.0
|
|
Min bending diameter (mm)
|
≤12
|
|
High temperature bending test
|
80℃,24h,Φ30mm, No rupture
|
|
Coating detachment rate(N)
|
≥20
|
