1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced

Central Strength Member (FRP Rod) ​ Φ1.7

Like any construction material, there are pros and cons to the use of FRP members:

• Due to its higher flexibility, typically elastic behavior, and emerging findings from ongoing research, current applicable design codes significantly reduce the allowable stress capacity that can be assumed when designing with FRP. Engineers must take into consideration the more stringent strength reduction factors and environmental reduction factors in the applicable design guidelines when designing with FRP reinforcing.
• Due to the manufacturing processes currently in use and the progressive standardization that they are undergoing, requirements for project specific acceptance testing of FRP can be more extensive compared to those which are required for traditional steel and concrete materials.
• Storage and handling requirements for FRP reinforcing on the construction site can be more restrictive due to FRP's susceptibility to damage from improper cutting, drilling, lifting techniques or aggressive handling.
• The initial cost of the FRP reinforcing is considerably higher than traditional materials. However, this higher initial cost may be partially offset by a reduction in the loads and the elimination of expensive corrosion-resistant prestressing or corrosion inhibiting admixtures typically used for steel reinforced concrete construction in extremely aggressive environments. A longer service life of the component may also be expected if FRP is used by reducing the need for repairs and eliminating cathodic protection or sacrificial anodes.

Property	Values
Tensile strength (Mpa)	≥1500
Tensile modulus(Gpa)	≥50
Flexural strength(Mpa)	≥1100
Flexural modulus(Gpa)	≥50
Elongation at break (%)	≤4
Coefficient of linear thermal   expansion(-30-80℃)(1/℃)	＜8*10-6
Diameter tolerance (mm)	±2%
Minimum bending radius(mm)	40*D
Density (g/cm3)	2.05-2.15
High temperature bending test(50D,100℃,120h)	No bur, crack and   break
Low temperature bending test(50D,-40℃,120h)	No bur, crack and   break
Torsion (±360°/m)	Not disintegrated









Product Description

Fiber optical cable with FRP strength member 1/2/4 core single mode ftth drop wire cable



Most of the optical cables are single-core and double-core structures, and can also be made into a four-core structure. The cross-section is an 8-shaped cross-section. The reinforcement is located at the center of the two circles. The metal or non-metallic structure can be used. The optical fiber is located at the geometric center of the 8-shaped geometry. . G.657 small bending radius optical fiber is used for the optical fiber in the sheathed cable, which can be laid with a bending radius of 20mm, which is suitable for entering the house in the building by means of pipes or bum lines.







Product features:

1, Special bending-resistant optical fiber, providing greater bandwidth and enhancing network transmission performance

2, Two parallel FRP or metal reinforcements make the optical cable have good pressure resistance and protect the optical fiber

3, The optical cable has simple structure, light weight and strong practicability

4, Unique groove design, easy to peel, easy to connect, simplify installation and maintenance;

5,Low-smoke halogen-free flame-retardant polyethylene sheath or flame-retardant PVC sheath, environmental protection

6,It can be matched with a variety of on-site connectors and can be completed on-site.





Application





1. Used for indoor wiring, directly used by end users;

2. Used for building optical fiber cables;

3. For indoor wiring of users in FTTH.
