Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced

Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced

  • Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced
Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced
Product Details:
Place of Origin: China
Brand Name: Dingrong
Certification: ISO9001
Model Number: Φ1.7
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Plywood reel or plastic reel
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 5000Km/Month
Contact Now
Detailed Product Description
Product Name: FRP Strength Material: Glass Fiber Reinforced Plastic
Function: Strengthen Packing: Plywood Reel Or Plastic Reel
Spool Length: 50.4km/reel, 25.2km/reel Or Customized High Temperature Bending Test (100℃, 24h, 30D): No Cracks, No Uneven Spots, Surface Smooth
High Light:

1.7mm Strength FRP Member


Customized FRP Member


OEM plastic FRP Member

customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced



Like any construction material, there are pros and cons to the use of FRP members:

  • Due to its higher flexibility, typically elastic behavior, and emerging findings from ongoing research, current applicable design codes significantly reduce the allowable stress capacity that can be assumed when designing with FRP. Engineers must take into consideration the more stringent strength reduction factors and environmental reduction factors in the applicable design guidelines when designing with FRP reinforcing.
  • Due to the manufacturing processes currently in use and the progressive standardization that they are undergoing, requirements for project specific acceptance testing of FRP can be more extensive compared to those which are required for traditional steel and concrete materials.
  • Storage and handling requirements for FRP reinforcing on the construction site can be more restrictive due to FRP's susceptibility to damage from improper cutting, drilling, lifting techniques or aggressive handling.
  • The initial cost of the FRP reinforcing is considerably higher than traditional materials. However, this higher initial cost may be partially offset by a reduction in the loads and the elimination of expensive corrosion-resistant prestressing or corrosion inhibiting admixtures typically used for steel reinforced concrete construction in extremely aggressive environments. A longer service life of the component may also be expected if FRP is used by reducing the need for repairs and eliminating cathodic protection or sacrificial anodes.


frp rod
Brand OEM
材Material Fiber glass and resin
Feature High tensile strength, high modulus
Surface Treatmen Smooth
Dimensions 0.40-5.00 mm
Standard ISO/GB
Delivery Length 50km/reel, 25km/reel or customized
Application Strength Member for Fiber Optic Cables
Technique Pultrusion
Certification ISO9001:2008, SGS
Packing Plywood reel or plastic reel
QC System: 100% Strict Inspection
Operating Tempera -40°C~+60°C
color white



Property Values
Tensile strength (Mpa) ≥1500
Tensile modulus(Gpa) ≥50
Flexural strength(Mpa) ≥1100
Flexural modulus(Gpa) ≥50
Elongation at break (%) ≤4

Coefficient of linear thermal



Diameter tolerance (mm) ±2%
Minimum bending radius(mm) 40*D
Density (g/cm3) 2.05-2.15
High temperature bending test(50D,100℃,120h)

No bur, crack and



Low temperature bending test(50D,-40℃,120h)

No bur, crack and



Torsion (±360°/m) Not disintegrated





Product Description

Fiber optical cable with FRP strength member 1/2/4 core single mode ftth drop wire cable


Most of the optical cables are single-core and double-core structures, and can also be made into a four-core structure. The cross-section is an 8-shaped cross-section. The reinforcement is located at the center of the two circles. The metal or non-metallic structure can be used. The optical fiber is located at the geometric center of the 8-shaped geometry. . G.657 small bending radius optical fiber is used for the optical fiber in the sheathed cable, which can be laid with a bending radius of 20mm, which is suitable for entering the house in the building by means of pipes or bum lines.




Product features:

1, Special bending-resistant optical fiber, providing greater bandwidth and enhancing network transmission performance

2, Two parallel FRP or metal reinforcements make the optical cable have good pressure resistance and protect the optical fiber
3, The optical cable has simple structure, light weight and strong practicability
4, Unique groove design, easy to peel, easy to connect, simplify installation and maintenance;
5,Low-smoke halogen-free flame-retardant polyethylene sheath or flame-retardant PVC sheath, environmental protection
6,It can be matched with a variety of on-site connectors and can be completed on-site.
Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced 0

Customized 1.7mm Strength FRP Member Corrosion Resistant OEM Glass Fiber Reinforced 1




1. Used for indoor wiring, directly used by end users;

2. Used for building optical fiber cables;

3. For indoor wiring of users in FTTH.


1.About the price?
Re.We usually quote within 12 hours after we confirm the technical data of your products.

2.What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.

3.What are your terms of payment?
Re.30% in advance,and 70% before shipment

4.How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.

5.How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
