Wuxi Dingrong Composite Material Technology Co. Ltd
We grow with you！
 |
| Place of Origin: | China |
| Brand Name: | Dingrong |
| Certification: | ISO9001 |
| Model Number: | Φ0.4-Φ5.0 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood reel or plastic reel |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000Km/Month |
| Spool Length: | 50.4km/reel, 25.2km/reel Or Customized | Function: | FRP Strength Member |
|---|---|---|---|
| Product Name: | FRP Reinforcement | Material: | FRP |
| Packing: | Plywood Reel Or Plastic Reel | High Temperature Bending Test (100℃, 24h, 30D): | No Cracks, No Uneven Spots, Surface Smooth |
| Number Of Conductors: | ≥ 10,2,4,8,12 | Color: | Customized |
| Oem: | Available | ||
| High Light: | Anti Corrosion FRP Member,CSM Reinforcement FRP Member,CSM Fiber reinforced polymers Member |
||
CSM FRP Member FRP Reinforcement Rod Anti Corrosion FRP Strength Member
Optical Fiber Cable Strength Member Features:
1. Specification: 0.4mm-5.0mm (Diameter)
2. Features:
1) High tensile and light weight
2) Electromagnetic interference free
3) Anti-corrosion
4) Environmentally friendly
5) Bullet-proof, ant-proof and anti-tooth proof
3. Application: It is widely used as the central strengthen core for the various fiber optical cables
Specification Of FRP
High tensile strength, high modulus, low heat conductivity, low stretch, low expansion, wide range of temperature settings.
Insensitive to electric shock, suitable for the area with frequent lightning and raining.
Free from chemical corrosion. Compared with metal wire,FRP rod eliminates harmful gas, which can negatively affect cables transmission quality, born chemically by metal and filling gel.
Compared with metal wire, FRP is of high strength, low weight, excellent insulation and immune to electromagnetic interference.
Optical fiber cables with FRP are available to be installed tight close to power wire and power units, perfectly insulated, free from induction current interference. The transmission efficiency can be improved accordingly.
Smooth surface, stable sizes, easy processing and installation contribute to wide range of FRP strength member application.
| Property | Value |
| Appearance | No deffets harmful use such as cracks, uneven spots, and contamination |
| Tensile strength | ≥1100 Mpa |
| Tensile modulus | ≥50 Gpa |
| Flexural strength | ≥1100 Mpa |
| Flexural modulus | ≥50 Gpa |
| Elongation at break | ≤4 % |
| Diameter tolerance | ±2% mm |
| Minimum bending radius | 40*D mm |
| Density (g/cm3) | 2.05-2.15 |
| High temperature bending test (50D,100℃,120h) | No bur, crack and break |
| Low temperature bending test (50D,-40℃,120h) | No bur, crack and break |
