ISO FRP Reinforced Member Plastic Rods For Fiber Optic Cables
Product Details
ISO Fiber Reinforced FRP Member
,Fiber Optic Cables FRP Member
,Plastic FRP Rods Member
ISO Qualified Fiber Reinforced Plastic FRP Rods For Fiber Optic Cables
• Light Weight & Excellent Tensile Strength
• Prevent Cable Buckling
• Most Suited for Multi-Loose Tube, Uni Tube, Slotted Core & Ribbon Cable Designs
• Used as Central or Peripheral Reinforcement in Fibre Optic Cables
• Dual Advantage : Reinforcement during Installation as well as Reduce Stress on Signal Carrying Optic Fibre /Conductor
• Prevent Sagging in Aerial Installation
• Cost Effective Solution as a Strength Member
| Property | Values |
| Tensile strength (Mpa) | ≥1500 |
| Tensile modulus(Gpa) | ≥50 |
| Flexural strength(Mpa) | ≥1100 |
| Flexural modulus(Gpa) | ≥50 |
| Elongation at break (%) | ≤4 |
|
Coefficient of linear thermal
expansion(-30-80℃)(1/℃) |
＜8*10-6 |
| Diameter tolerance (mm) | ±2% |
| Minimum bending radius(mm) | 40*D |
| Density (g/cm3) | 2.05-2.15 |
| High temperature bending test(50D,100℃,120h) |
No bur, crack and
break |
| Low temperature bending test(50D,-40℃,120h) |
No bur, crack and
break |
| Torsion (±360°/m) | Not disintegrated |
Characteristics
Fiber optical cable with FRP strength member 1/2/4 core single mode ftth drop wire cable
Most of the optical cables are single-core and double-core structures, and can also be made into a four-core structure. The cross-section is an 8-shaped cross-section. The reinforcement is located at the center of the two circles. The metal or non-metallic structure can be used. The optical fiber is located at the geometric center of the 8-shaped geometry. . G.657 small bending radius optical fiber is used for the optical fiber in the sheathed cable, which can be laid with a bending radius of 20mm, which is suitable for entering the house in the building by means of pipes or bum lines.
Product features:
1, Special bending-resistant optical fiber, providing greater bandwidth and enhancing network transmission performance
Application
1. Used for indoor wiring, directly used by end users;
2. Used for building optical fiber cables;
3. For indoor wiring of users in FTTH.
1.About the price?
Re.We usually quote within 12 hours after we confirm the technical data of your products.
2.What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.
3.What are your terms of payment?
Re.30% in advance,and 70% before shipment
4.How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.
5.How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
