| Place of Origin: | China |
| Brand Name: | Dingrong |
| Certification: | ISO9001 |
| Model Number: | Φ0.4-Φ5.0 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood reel or plastic reel |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000Km/Month |
| Product Name: | FRP Strength | Material: | Glass Fiber Reinforced Plastic |
|---|---|---|---|
| Function: | Strengthen | Packing: | Plywood Reel Or Plastic Reel |
| Spool Length: | 50.4km/reel, 25.2km/reel Or Customized | High Temperature Bending Test (100℃, 24h, 30D): | No Cracks, No Uneven Spots, Surface Smooth |
| Highlight: | Glass FRP Strength Member,2.5mm Fiber Reinforced Plastic Strength Member,smooth FRP Member |
||
2.5mm Glass Fiber Reinforced Plastic Strength Member
The structural strength of optical cable is an important index of the mechanical properties of optical cable. As one of the structural components of fixed optical cable, the FRP reinforcing core plays an important role in strengthening the tensile and compressive capacity of optical cable.
FRP glass fiber reinforced core, as a kind of structural strengthening element of non-metallic fiber optic cable, is widely accepted and used by the fiber optic cable industry. It is a non-metallic bearing core with good price and performance generally recognized by the fiber optic cable industry at home and abroad. To produce qualified FRP, the key lies in the reasonable selection of reinforcement materials (glass fiber), base materials (resin) and curing process.
Features
|
1 |
Insensitive to the lightning strike, suitable for the area with frequent lightning and rain. |
|
2 |
Free from the induction interference, can be laid and installed close to the power line and device. |
|
3 |
No harmful gas, which will affect the transmission of the optical fiber, will be given off from the corrosive metal. |
|
4 |
FRP Strength Member has a high ratio of strength/weight. |
Standard DIameters
| 1.1 mm | 1.5 mm | 2.0 mm | 2.2 mm |
| 2.3 mm | 2.5 mm | 2.7 mm | 3.0 mm |
| 3.1 mm | 3.5 mm | 3.7 mm | 4.0 mm |
|
Description
|
FRP Factory Price Non-Metallic FRP Strength Member for Optical Cables
|
|
Place of Origin
|
Wuxi, China (Mainland)
|
|
Material
|
Fiber Glass and Resin
|
|
Color
|
White
|
|
Diameter Range
|
0.40 mm-5.00 mm
|
|
MOQ
|
100 Kilometers
|
|
Delivery Length
|
50km/reel, 25km/reel, or customized
|
|
Packing Details
|
50km FRP rod in one reel, 25km FRP rod in one reel, plywood reel or plastic reel available
|
|
Lead Time
|
3 days for the stock FRP;
15 days after receipt of prepayment for the new order
|
Technical characteristics:
1. It has the characteristics of light weight and high strength.
2. It has good corrosion resistance and impact resistance. This optical cable is rust proof, tooth biting proof and ant proof.
3. The surface is smooth and the size is more stable.
4. The chemical reaction between metal and other optical cable materials will not affect the optical fiber transmission index.
5. It is not sensitive to electric shock current, and is suitable for multi lightning, multi rain and other climate environment
Application
1. Used for indoor wiring, directly used by end users;
2. Used for building optical fiber cables;
3. For indoor wiring of users in FTTH.
1. About the price?
Re.We usually quote within 12 hours after we confirm the technical data of your products.
2. What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.
3. What are your terms of payment?
Re.30% in advance,and 70% before shipment
4. How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.
5. How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
