| Place of Origin: | China |
| Brand Name: | Dingrong |
| Certification: | ISO9001 |
| Model Number: | Φ0.4-Φ5.0 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood reel or plastic reel |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000Km/Month |
| Product Name: | Strengthen Core | Material: | FRP |
|---|---|---|---|
| Function: | Strength | Packing: | Plywood Reel |
| Spool Length: | 50.4km/reel, 25.2km/reel Or Customized | High Temperature Bending Test (100℃, 24h, 30D): | No Cracks, No Uneven Spots, Surface Smooth |
| High Light: | Plywood reel FRP Strength Member,Fiber Optical Cables FRP Member,FRP Member no uneven spots |
||
FRP Strength Member for Fiber Optic Cable/FRP rod Φ0.4-Φ5.0
FRP strength member is widely used as the central strengthen core for the various fiber optical cables
FRP strength member overcomes the defects of traditional metal cable reinforcements, has excellent corrosion resistance, lightning resistance, electromagnetic field interference resistance, high tensile strength, light weight, environmental protection, energy saving, etc., and is widely used in a variety of fiber optic cable.
FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio. Without drawbacks of traditional metallic strength member, FRP rod features excellent anti-corrosion, electromagnetic interference free, high tensile strength, low weight, saving energy and environmentally friendly, which are now widely used in various optical fiber cables.
|
Feature
|
High tensile strength, high modulus
|
|
Surface Treatmen
|
Smooth
|
|
Dimensions
|
0.40-5.00 mm
|
|
Standard
|
ISO/GB
|
|
Delivery Length
|
50km/reel, 25km/reel or customized
|
|
Application
|
Strength Member for Fiber Optic Cables
|
|
Technique
|
Pultrusion
|
|
Certification
|
ISO9001:2008, SGS
|
|
Packing
|
Plywood reel or plastic reel
|
|
QC System:
|
100% Strict Inspection
|
|
Operating Tempera
|
-40°C~+60°C
|
|
color
|
white
|
Features:
* High tensile strength, high modulus, low thermal conductivity, low elongation, low expansion, and wide temperature range;
* Non-metallic materials are not sensitive to electric shock, and are suitable for areas with multiple lightning and rainy
weather conditions;
* Chemical resistance, compared with the metal core, the GFRP reinforcing core does not affect the fiber transmission index
* The fiber optic cable using the GFRP reinforcing core can be installed next to the power line and the power supply device, and
is not interfered by the induced current generated by the power line
* Smooth surface, stable size, easy to process and lay, and the application range is wide.
