| Place of Origin: | China |
| Brand Name: | Dingrong |
| Certification: | ISO9001 |
| Model Number: | Φ0.4-Φ5.0 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood reel or plastic reel |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000Km/Month |
| Spool Length: | 50.4km/reel, 25.2km/reel Or Customized | Function: | FRP Strength Member |
|---|---|---|---|
| Product Name: | FRP Reinforcement | Material: | FRP |
| Packing: | Plywood Reel Or Plastic Reel | High Temperature Bending Test (100℃, 24h, 30D): | No Cracks, No Uneven Spots, Surface Smooth |
| Number Of Conductors: | ≥ 10,2,4,8,12 | Color: | Customized |
| Oem: | Available | ||
| Highlight: | 3mm Frp Rods,High Tensile FRP Strength Member,no cracks Frp Rods |
||
3mm Frp Rods High Tensile FRP Strength Member
Non-metallic FRP Strength Member, a di-electric composite cable strength member widely known as FRP/ GRP rod, is to use vinyl ester resin as foundation combined with the strength of glass fiber through pultrusion technology to produce a new type of high performance non-metallic composite material. Without drawbacks of traditional metallic strength member, FRP strength member features excellent anti-corrosion, electromagnetic interference free, high tensile strength, low weight, saving energy and environmentally friendly, which are now widely used in various optical fiber cables.
Specification Of FRP
• Light Weight & Excellent Tensile Strength
• Prevent Cable Buckling
• Most Suited for Multi-Loose Tube, Uni Tube, Slotted Core & Ribbon Cable Designs
• Used as Central or Peripheral Reinforcement in Fibre Optic Cables
• Dual Advantage : Reinforcement during Installation as well as Reduce Stress on Signal Carrying Optic Fibre /Conductor
• Prevent Sagging in Aerial Installation
• Cost Effective Solution as a Strength Member
| Property | Value |
| Appearance | No deffets harmful use such as cracks, uneven spots, and contamination |
| Tensile strength | ≥1100 Mpa |
| Tensile modulus | ≥50 Gpa |
| Flexural strength | ≥1100 Mpa |
| Flexural modulus | ≥50 Gpa |
| Elongation at break | ≤4 % |
| Diameter tolerance | ±2% mm |
| Minimum bending radius | 40*D mm |
| Density (g/cm3) | 2.05-2.15 |
| High temperature bending test (50D,100℃,120h) | No bur, crack and break |
| Low temperature bending test (50D,-40℃,120h) | No bur, crack and break |
